LCC10-14AWH-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 10-14AWG 39.87mm 10.66mm Electro-Tin
PDF
/
Inventory: 8095
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.220 (5.59mm)
Diameter - Barrel ID 0.130 (3.30mm)
Tab Thickness 0.050 1.27mm
Width - Outer Edges 0.420 10.67mm
Length 39.87mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 10 AWG
Body Plating Tin
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 14 AWG
Wire Gauge 10 AWG
Contact Finish Electro-Tin
Depth 10.66mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
