LCC1-56BF-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 1AWG 55.6mm 17.8mm Tin
PDF
/
Inventory: 7571
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Green
HTS Code 8536.90.40.00
Depth 17.8mm
Contact Finish Electro-Tin
Wire Gauge 1 AWG
Body Plating Tin
Wire/Cable Gauge 1 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/16 Stud
Terminal Style Two Stud Holes
Dimensions
Length 55.6mm
Width - Outer Edges 0.700 17.78mm
Tab Thickness 0.110 2.79mm
Diameter - Barrel ID 0.360 (9.14mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Ring ID 0.340 (8.64mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
