LCC1/0-56CF-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (1/0)AWG 60.5mm 19.3mm Tin
PDF
/
Buying Options
Total Price: USD $13.89
Unit Price: USD $13.894674
≥1 USD $13.894674
≥10 USD $13.108186
≥100 USD $12.366216
≥500 USD $11.666242
≥1000 USD $11.005887
Inventory: 4028
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Pink
HTS Code 8536.90.40.00
Depth 19.3mm
Contact Finish Electro-Tin
Wire Gauge 1/0 AWG
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Wire Cross Section 53.51 mm2
Stud/Tab Size 5/16 Stud
Terminal Style Two Stud Holes
Dimensions
Length 60.5mm
Width - Outer Edges 0.760 19.30mm
Tab Thickness 0.120 3.05mm
Diameter - Barrel ID 0.390 (9.91mm)
Diameter - Barrel OD 0.520 (13.21mm)
Diameter - Ring ID 0.340 (8.64mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
