LCC1/0-14BF-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 19.3mm
PDF
/
Inventory: 1324
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.520 (13.21mm)
Diameter - Barrel ID 0.390 (9.91mm)
Tab Thickness 0.120 3.05mm
Width - Outer Edges 0.760 19.30mm
Length 55.9mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 1/0 AWG
Contact Finish Electro-Tin
Depth 19.3mm
HTS Code 8536.90.40.00
Color Pink
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
