LCC1/0-14A-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (1/0)AWG 80.77mm 19.3mm Electro-Tin
PDF
/
Buying Options
Total Price: USD $12.72
Unit Price: USD $12.716
≥1 USD $12.716
Inventory: 36
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.520 (13.21mm)
Diameter - Barrel ID 0.390 (9.91mm)
Tab Thickness 0.120 3.05mm
Width - Outer Edges 0.760 19.30mm
Length - Overall 3.180 80.78mm
Length 80.772mm
Technical
Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 1/0 AWG
Contact Finish Electro-Tin
Depth 19.3mm
HTS Code 8536.90.40.00
Color Pink
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
