LCBX4-14F-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 4AWG 28.5mm 14mm Tin
PDF
/
Buying Options
Total Price: USD $5.15
Unit Price: USD $5.153136
≥1 USD $5.153136
≥10 USD $4.861455
≥100 USD $4.586281
≥500 USD $4.326672
≥1000 USD $4.081766
Inventory: 4151
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2005
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Gray
HTS Code 8536.90.40.00
Depth 14mm
Contact Finish Electro-Tin
Wire Gauge 4 AWG
Body Plating Tin
Wire/Cable Gauge 4 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/4 Stud
Terminal Style Single Stud Hole
Dimensions
Length 28.5mm
Width - Outer Edges 0.550 13.97mm
Tab Thickness 0.090 2.29mm
Diameter - Barrel ID 0.280 (7.11mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Ring ID 0.270 (6.86mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
