LCBX4/0-12F-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 55.4mm 30.2mm Tin
PDF
/
Inventory: 3526
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Purple
HTS Code 8536.90.40.00
Depth 30.2mm
Contact Finish Electro-Tin
Wire Gauge 4/0 AWG
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole
Series Pan-Lug?
Published 2004
Packaging Bulk
Dimensions
Length 55.4mm
Width - Outer Edges 1.190 30.23mm
Tab Thickness 0.160 4.06mm
Diameter - Barrel ID 0.650 (16.51mm)
Diameter - Barrel OD 0.810 (20.57mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
