LCBX2-12-E

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal 2AWG 68.6mm 19.1mm Tin
PDF
/
Buying Options
Total Price: USD $18.36
Unit Price: USD $18.363532
≥1 USD $18.363532
≥200 USD $7.327295
≥500 USD $7.083096
≥1000 USD $6.962309
Inventory: 6274
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Brown
HTS Code 8536.90.40.00
Depth 19.1mm
Contact Finish Electro-Tin
Wire Gauge 2 AWG
Body Plating Tin
Wire/Cable Gauge 2 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole

Dimensions

Length 68.58mm
Length - Overall 2.700 68.58mm
Width - Outer Edges 0.750 19.05mm
Tab Thickness 0.090 2.29mm
Diameter - Barrel ID 0.360 (9.14mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Ring ID 0.530 (13.46mm)

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
