LCB800-58W-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (9.7/0)AWG 144.3mm 49.5mm Tin
PDF
/
Inventory: 6275
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Orange
HTS Code 8536.90.40.00
Depth 49.5mm
Contact Finish Electro-Tin
Wire Gauge 800MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/8 Stud
Terminal Style Single Stud Hole
Dimensions
Length 144.272mm
Length - Overall 5.680 144.27mm
Width - Outer Edges 1.950 49.53mm
Tab Thickness 0.300 7.62mm
Diameter - Barrel ID 1.050 (26.67mm)
Diameter - Barrel OD 1.350 (34.29mm)
Diameter - Ring ID 0.660 (16.76mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
