LCB8-14-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 8AWG 38.9mm 12.2mm Tin
PDF
/
Buying Options
Total Price: USD $2.36
Unit Price: USD $2.363873
≥1 USD $2.363873
≥10 USD $2.230076
≥100 USD $2.103838
≥500 USD $1.984751
≥1000 USD $1.872409
Inventory: 926
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.270 (6.86mm)
Diameter - Barrel ID 0.180 (4.57mm)
Tab Thickness 0.070 1.78mm
Width - Outer Edges 0.480 12.19mm
Length - Overall 1.530 38.86mm
Length 38.862mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 8 AWG
Wire Gauge 8 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Gender Male
Color Red
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Weight 358.338001g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
