LCB750-58-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (9.5/0)AWG 151.9mm 48mm Tin
PDF
/
Buying Options
Total Price: USD $91.69
Unit Price: USD $91.694249
≥1 USD $91.694249
≥200 USD $36.586584
≥500 USD $35.364274
≥1000 USD $34.76034
Inventory: 6176
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.660 (16.76mm)
Diameter - Barrel OD 1.300 (33.02mm)
Diameter - Barrel ID 1.030 (26.16mm)
Tab Thickness 0.260 6.60mm
Width - Outer Edges 1.890 48.01mm
Length - Overall 5.980 151.89mm
Length 151.892mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 5/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Wire Gauge 750MCM (kcmil)
Contact Finish Electro-Tin
Color Black
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
