LCB750-12W-6
RoHS
RoHS compliant
RoHS compliantPackage 127
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 48mm
PDF
/
Inventory: 4423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 1.300 (33.02mm)
Diameter - Barrel ID 1.030 (26.16mm)
Tab Thickness 0.260 6.60mm
Width - Outer Edges 1.890 48.01mm
Length - Overall 5.020 127.51mm
Length 127.508mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 750MCM (kcmil)
Contact Finish Electro-Tin
Depth 48mm
HTS Code 8536.90.40.00
Color Black
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Package / Case 127
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
