LCB500-78F-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (7.7/0)AWG 95.8mm 39.1mm Tin
PDF
/
Inventory: 5310
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 7/8 Stud
Terminal Style Single Stud Hole
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge 500MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Dimensions
Width - Outer Edges 1.540 39.12mm
Tab Thickness 0.220 5.59mm
Diameter - Barrel ID 0.840 (21.34mm)
Diameter - Barrel OD 1.060 (26.92mm)
Diameter - Ring ID 0.910 (23.11mm)
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
