LCB500-58-6
RoHS
RoHS compliant
RoHS compliantPackage 120
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (7.7/0)AWG 120.4mm 39.1mm Tin
PDF
/
Buying Options
Total Price: USD $59.8
Unit Price: USD $59.798656
≥1 USD $59.798656
≥200 USD $23.860645
≥500 USD $23.063714
≥1000 USD $22.668531
Inventory: 8876
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case 120
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Brown
HTS Code 8536.90.40.00
Depth 39.1mm
Contact Finish Electro-Tin
Wire Gauge 500MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Wire Cross Section 253.3 mm2
Stud/Tab Size 5/8 Stud
Terminal Style Single Stud Hole
Terminal Gender FEMALE
Dimensions
Length 120.396mm
Length - Overall 4.740 120.40mm
Width - Outer Edges 1.540 39.12mm
Tab Thickness 0.220 5.59mm
Diameter - Barrel ID 0.840 (21.34mm)
Diameter - Barrel OD 1.060 (26.92mm)
Diameter - Ring ID 0.660 (16.76mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
