LCB350-78-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (6.2/0)AWG 121.4mm 32.5mm Tin
PDF
/
Inventory: 6431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Depth 32.5mm
Contact Finish Electro-Tin
Wire Gauge 350MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Wire Cross Section 177.3 mm2
Stud/Tab Size 7/8 Stud
Terminal Style Single Stud Hole
Terminal Gender FEMALE
Dimensions
Length 120.904mm
Length - Overall 4.760 120.90mm
Width - Outer Edges 1.280 32.51mm
Tab Thickness 0.170 4.32mm
Diameter - Barrel ID 0.700 (17.78mm)
Diameter - Barrel OD 0.880 (22.35mm)
Diameter - Ring ID 0.910 (23.11mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
