LCB1000-12W-3

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal (10.7/0)AWG 133.9mm 55.1mm Tin
PDF
/
Buying Options
Total Price: USD $92.95
Unit Price: USD $92.9544
≥1 USD $92.9544
≥10 USD $90.30208
≥100 USD $82.334472
Inventory: 40
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Tab Thickness 0.320 8.13mm
Width - Outer Edges 2.170 55.12mm
Length - Overall 5.270 133.86mm
Length 133.858mm

Technical

Terminal Gender FEMALE
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 1000MCM (kcmil)
Contact Finish Electro-Tin
Depth 55.1mm
HTS Code 8536.90.40.00
Color White
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
