LCB1-10F-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 1AWG 50.8mm 17.8mm Tin
PDF
/
Inventory: 2511
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.200 (5.08mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Barrel ID 0.360 (9.14mm)
Tab Thickness 0.110 2.79mm
Width - Outer Edges 0.700 17.78mm
Length 50.8mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 10 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 1 AWG
Body Plating Tin
Wire Gauge 1 AWG
Contact Finish Electro-Tin
Depth 17.8mm
HTS Code 8536.90.40.00
Color Green
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
Alternative Model
