LCAX650-38H-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT TONG 650 MCM #3/8
PDF
/
Inventory: 8318
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2011
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Black
HTS Code 8536.90.40.00
Depth 49.5mm
Contact Finish Electro-Tin
Wire Gauge 650MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Single Stud Hole
Dimensions
Length 73.4mm
Width - Outer Edges 1.950 49.53mm
Tab Thickness 0.300 7.62mm
Diameter - Barrel ID 1.050 (26.67mm)
Diameter - Barrel OD 1.350 (34.29mm)
Diameter - Ring ID 0.410 (10.41mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
