LCAX4-10F-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 4AWG 26.2mm 14mm Tin
PDF
/
Buying Options
Total Price: USD $3.8
Unit Price: USD $3.800832
≥1 USD $3.800832
≥10 USD $3.585692
≥100 USD $3.382736
≥500 USD $3.191251
≥1000 USD $3.010618
Inventory: 969
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.200 (5.08mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Barrel ID 0.280 (7.11mm)
Tab Thickness 0.090 2.29mm
Width - Outer Edges 0.550 13.97mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 10 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge 4 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Gray
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
