LCAX4/0-58-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 72.4mm 30.2mm Tin
PDF
/
Buying Options
Total Price: USD $13.15
Unit Price: USD $13.1472
≥1 USD $13.1472
≥10 USD $12.78992
≥100 USD $12.4344
≥500 USD $12.079232
≥1000 USD $11.723976
≥3000 USD $11.368685
Inventory: 677
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.660 (16.76mm)
Diameter - Barrel OD 0.810 (20.57mm)
Diameter - Barrel ID 0.650 (16.51mm)
Tab Thickness 0.160 4.06mm
Width - Outer Edges 1.190 30.23mm
Length - Overall 2.850 72.40mm
Thickness 4.064mm
Length 72.39mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 5/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge 4/0 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Purple
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
