LCAX350-38F-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (6.2/0)AWG 58.9mm 39.1mm Tin
PDF
/
Buying Options
Total Price: USD $19.77
Unit Price: USD $19.7736
≥1 USD $19.7736
Inventory: 239
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Depth 39.1mm
Contact Finish Electro-Tin
Wire Gauge 350MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Single Stud Hole
Dimensions
Length 58.9mm
Width - Outer Edges 1.540 39.12mm
Tab Thickness 0.220 5.59mm
Diameter - Barrel ID 0.840 (21.34mm)
Diameter - Barrel OD 1.060 (26.92mm)
Diameter - Ring ID 0.410 (10.41mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
