LCAX350-38-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (6.2/0)AWG 74.4mm 39.1mm Tin
PDF
/
Buying Options
Total Price: USD $17.49
Unit Price: USD $17.4856
≥1 USD $17.4856
≥10 USD $17.00336
≥100 USD $16.517248
≥500 USD $16.031312
≥1000 USD $15.545552
≥3000 USD $15.059792
Inventory: 118
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Depth 39.1mm
Contact Finish Electro-Tin
Wire Gauge 350MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Terminal Style Single Stud Hole
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 1.060 (26.92mm)
Diameter - Barrel ID 0.840 (21.34mm)
Tab Thickness 0.220 5.59mm
Width - Outer Edges 1.540 39.12mm
Length - Overall 2.930 74.42mm
Length 74.422mm
