LCAX2-12-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 2AWG 49.3mm 19.1mm Tin
PDF
/
Buying Options
Total Price: USD $6.05
Unit Price: USD $6.0544
≥1 USD $6.0544
≥10 USD $5.89424
≥100 USD $5.402848
≥500 USD $5.075365
Inventory: 180
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Barrel ID 0.360 (9.14mm)
Tab Thickness 0.090 2.29mm
Width - Outer Edges 0.750 19.05mm
Length - Overall 1.940 49.28mm
Length 49.276mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 2 AWG
Body Plating Tin
Wire Gauge 2 AWG
Contact Finish Electro-Tin
Depth 19.1mm
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
