LCAX1/0-38-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals Copper Comp Lug 1 Hole 1/0 AWG
PDF
/
Buying Options
Total Price: USD $6.54
Unit Price: USD $6.5384
≥1 USD $6.5384
≥10 USD $6.36064
≥100 USD $6.183936
≥500 USD $6.007056
≥1000 USD $5.83044
≥3000 USD $5.653754
Inventory: 352
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.580 (14.73mm)
Diameter - Barrel ID 0.450 (11.43mm)
Tab Thickness 0.130 3.30mm
Width - Outer Edges 0.850 21.59mm
Length - Overall 1.890 48.01mm
Length 48.006mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 1 AWG
Body Plating Tin
Wire Gauge 1/0 AWG
Contact Finish Electro-Tin
Depth 21.6mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Male
Color Pink
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Weight 294.835069g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
