LCAS8-10H-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 8AWG 25.4mm 10.4mm Tin
PDF
/
Inventory: 5571
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.200 (5.08mm)
Diameter - Barrel OD 0.270 (6.86mm)
Diameter - Barrel ID 0.180 (4.57mm)
Tab Thickness 0.080 2.03mm
Width - Outer Edges 0.410 10.41mm
Length 25.4mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 10 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 8 AWG
Body Plating Tin
Wire Gauge 8 AWG
Contact Finish Electro-Tin
Depth 10.4mm
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
