LCAS6-56F-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 6AWG 14.2mm
PDF
/
Inventory: 1568
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.340 (8.64mm)
Diameter - Barrel OD 0.310 (7.87mm)
Diameter - Barrel ID 0.220 (5.59mm)
Tab Thickness 0.070 1.78mm
Width - Outer Edges 0.560 14.22mm
Length 29.2mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 5/16 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 6 AWG
Body Plating Tin
Wire Gauge 6 AWG
Contact Finish Electro-Tin
Depth 14.2mm
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
