LCAS3/0-38-X

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal (3/0)AWG 51.6mm 24.4mm Tin
PDF
/
Inventory: 4716
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.640 (16.26mm)
Diameter - Barrel ID 0.510 (12.95mm)
Tab Thickness 0.130 3.30mm
Width - Outer Edges 0.960 24.38mm
Length - Overall 2.030 51.56mm
Length 51.562mm

Technical

Terminal Gender FEMALE
Terminal Style Single Stud Hole
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 3/0 AWG
Contact Finish Electro-Tin
Depth 24.4mm
HTS Code 8536.90.40.00
Color Orange
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2001
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
