LCAS2-38H-Q

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal 2AWG 37.1mm 16.8mm Tin
PDF
/
Inventory: 4211
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Body Material Copper

Technical

Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Color Brown
Depth 16.8mm
Contact Finish Electro-Tin
Wire Gauge 2 AWG
Body Plating Tin
Wire/Cable Gauge 2 AWG
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Single Stud Hole

Dimensions

Length 37.1mm
Width - Outer Edges 0.660 16.76mm
Tab Thickness 0.100 2.54mm
Diameter - Barrel ID 0.310 (7.87mm)
Diameter - Barrel OD 0.420 (10.67mm)
Diameter - Ring ID 0.410 (10.41mm)

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
