LCAS1-56H-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 1AWG 36.1mm 17.8mm Tin
PDF
/
Buying Options
Total Price: USD $5.96
Unit Price: USD $5.960907
≥1 USD $5.960907
≥10 USD $5.623501
≥100 USD $5.305192
≥500 USD $5.004895
≥1000 USD $4.721606
Inventory: 7995
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Green
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 1 AWG
Wire/Cable Gauge 1 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/16 Stud
Terminal Style Single Stud Hole
Terminal Gender FEMALE
Dimensions
Width - Outer Edges 0.700 17.78mm
Tab Thickness 0.110 2.79mm
Diameter - Barrel ID 0.360 (9.14mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Ring ID 0.340 (8.64mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
