LCAS1/0-56F-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 19.3mm
PDF
/
Inventory: 8733
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Pink
HTS Code 8536.90.40.00
Depth 19.3mm
Contact Finish Electro-Tin
Wire Gauge 1/0 AWG
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/16 Stud
Terminal Style Single Stud Hole
Dimensions
Length 38.4mm
Width - Outer Edges 0.760 19.30mm
Tab Thickness 0.120 3.05mm
Diameter - Barrel ID 0.390 (9.91mm)
Diameter - Barrel OD 0.520 (13.21mm)
Diameter - Ring ID 0.340 (8.64mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
