LCAN2-10-Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals Cu COMPRSSN LUG 1H STD BRRL #2
PDF
/
Buying Options
Total Price: USD $6.7
Unit Price: USD $6.6968
≥1 USD $6.6968
≥10 USD $6.5164
≥100 USD $6.334944
≥500 USD $6.154016
≥1000 USD $5.973
≥3000 USD $5.791984
Inventory: 114
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.200 (5.08mm)
Diameter - Barrel OD 0.420 (10.67mm)
Diameter - Barrel ID 0.310 (7.87mm)
Tab Thickness 0.120 3.05mm
Width - Outer Edges 0.420 10.67mm
Length - Overall 1.670 42.42mm
Length 42.4mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 10 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Wire/Cable Gauge 2 AWG
Body Plating Tin
Wire Gauge 2 AWG
Contact Finish Electro-Tin
Depth 10.7mm
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Weight 346.998191g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
