LCAN2/0-56-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (2/0)AWG 53.1mm 13.2mm Tin
PDF
/
Buying Options
Total Price: USD $8.84
Unit Price: USD $8.844
≥1 USD $8.844
≥10 USD $8.60288
≥100 USD $8.363872
≥500 USD $8.12504
≥1000 USD $7.886032
≥3000 USD $7.647059
Inventory: 126
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 385.553543g
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Black
Gender Female
HTS Code 8536.90.40.00
Depth 13.2mm
Contact Finish Electro-Tin
Wire Gauge 2/0 AWG
Wire Gauge (Max) 0 AWG
Wire Gauge (Min) 2 AWG
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/16 Stud
Terminal Style Single Stud Hole
Dimensions
Length 53.086mm
Length - Overall 2.090 53.09mm
Width - Outer Edges 0.580 14.73mm
Tab Thickness 0.140 3.56mm
Diameter - Barrel ID 0.450 (11.43mm)
Diameter - Barrel OD 0.580 (14.73mm)
Diameter - Ring ID 0.340 (8.64mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
