LCAF6-56F-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 6AWG 30mm 14.2mm Tin
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.596
≥1 USD $2.596
≥10 USD $2.52384
Inventory: 83
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Terminal Style Single Stud Hole
Stud/Tab Size 5/16 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 6 AWG
Wire Gauge 6 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp, Barrel
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.340 (8.64mm)
Diameter - Barrel OD 0.370 (9.40mm)
Diameter - Barrel ID 0.220 (5.59mm)
Tab Thickness 0.070 1.78mm
Width - Outer Edges 0.560 14.22mm
