LCAF500-58-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (7.7/0)AWG 131.6mm 48mm Tin
PDF
/
Buying Options
Total Price: USD $38.67
Unit Price: USD $38.6672
≥1 USD $38.6672
≥10 USD $37.59536
≥100 USD $34.373152
≥500 USD $33.299033
Inventory: 32
Minimum: 1
-
+
Technical Details
Dimensions
Tab Thickness 0.260 6.60mm
Diameter - Barrel ID 1.030 (26.16mm)
Diameter - Barrel OD 1.550 (39.37mm)
Diameter - Ring ID 0.660 (16.76mm)
Width - Outer Edges 1.890 48.01mm
Length - Overall 5.180 131.57mm
Length 131.572mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 5/8 Stud
Wire Cross Section 345 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 500MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Gender Female
Color Pink
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Weight 2.290641kg
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
