LCAF4/0-14-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 65mm 29.7mm Tin
PDF
/
Buying Options
Total Price: USD $11.82
Unit Price: USD $11.8184
≥1 USD $11.8184
Inventory: 25
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.910 (23.11mm)
Diameter - Barrel ID 0.630 (16.00mm)
Tab Thickness 0.140 3.56mm
Width - Outer Edges 1.170 29.72mm
Length - Overall 2.560 65.02mm
Length 65.024mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 4/0 AWG
Contact Finish Electro-Tin
Depth 29.7mm
HTS Code 8536.90.40.00
Color Yellow
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
