LCAF300-12-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (3/0)AWG 85.6mm 35.3mm Tin
PDF
/
Buying Options
Total Price: USD $18.83
Unit Price: USD $18.832
≥1 USD $18.832
≥10 USD $18.31104
≥100 USD $16.741208
≥500 USD $16.218092
Inventory: 74
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 1.100 (27.94mm)
Diameter - Barrel ID 0.760 (19.30mm)
Tab Thickness 0.180 4.57mm
Width - Outer Edges 1.390 35.31mm
Length - Overall 3.370 85.60mm
Length 85.598mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 300MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
