LCAF3/0-12-X

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminals Copper Comp Lug 1 Hole 3/0 AWG
PDF
/
Buying Options
Total Price: USD $9.77
Unit Price: USD $9.768
≥1 USD $9.768
≥10 USD $9.504
≥100 USD $8.712176
≥500 USD $8.184176
Inventory: 262
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper
Mount Stud
Mounting Type Free Hanging (In-Line)
Weight 591.938043g

Technical

Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Purple
Gender Female
HTS Code 8536.90.40.00
Depth 26.92mm
Contact Finish Electro-Tin
Wire Gauge 3/0 AWG
Wire Gauge (Max) 0 AWG
Wire Gauge (Min) 3 AWG
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Lug, Grounding
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole

Dimensions

Length 71.88mm
Length - Overall 2.830 71.88mm
Width - Outer Edges 1.060 26.92mm
Tab Thickness 0.140 3.56mm
Diameter - Barrel ID 0.570 (14.48mm)
Diameter - Barrel OD 0.810 (20.57mm)
Diameter - Ring ID 0.530 (13.46mm)

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
