LCA8-10-L
RoHS
RoHS compliant
RoHS compliantPackage 600
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals COPPER COMPRESSION 1 HOLE #8 AWG #10
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.936
≥1 USD $1.936
≥10 USD $1.88408
≥100 USD $1.726736
≥500 USD $1.622086
Inventory: 4532
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.200 (5.08mm)
Diameter - Barrel OD 0.270 (6.86mm)
Diameter - Barrel ID 0.180 (4.57mm)
Tab Thickness 0.080 2.03mm
Width - Outer Edges 0.410 10.41mm
Length - Overall 1.250 31.75mm
Width 10.4mm
Length 31.75mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 10 Stud
Terminal Type Lug, Grounding
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 8 AWG
Body Plating Tin
Wire Gauge 8 AWG
Contact Finish Electro-Tin
Depth 10.41mm
Orientation Straight
HTS Code 8535.90.80.20
Gender Female
Color Red
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 1996
Packaging Bulk
Physical
Package / Case 600
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
