LCA500-34-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (7.7)/0AWG 99.1mm 39.1mm Tin
PDF
/
Buying Options
Total Price: USD $15.25
Unit Price: USD $15.245022
≥1 USD $15.245022
≥10 USD $14.382093
≥100 USD $13.568021
≥500 USD $12.800018
≥1000 USD $12.075488
Inventory: 7300
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.780 (19.81mm)
Diameter - Barrel OD 1.060 (26.92mm)
Diameter - Barrel ID 0.840 (21.34mm)
Tab Thickness 0.220 5.59mm
Width - Outer Edges 1.540 39.12mm
Length - Overall 3.890 98.81mm
Length 98.806mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 3/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 500MCM (kcmil)
Contact Finish Electro-Tin
Depth 39.1mm
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
