LCA4-12-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
GLOVE, POLYAMIDE, L/FREE, PU, SIZE 6 - More Details
PDF
/
Buying Options
Total Price: USD $4.66
Unit Price: USD $4.664
≥1 USD $4.664
≥10 USD $4.54168
≥100 USD $4.415136
≥500 USD $4.28912
≥1000 USD $4.162928
≥3000 USD $4.036824
Inventory: 79
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Barrel ID 0.280 (7.11mm)
Tab Thickness 0.070 1.78mm
Width - Outer Edges 0.750 19.05mm
Length - Overall 2.230 56.64mm
Length 56.642mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 4 AWG
Wire Gauge (Min) 2 AWG
Wire Gauge (Max) 4 AWG
Wire Gauge 2-4 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Gray
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
