LCA4/0-12-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 67.81mm 26.92mm Electro-Tin
PDF
/
Buying Options
Total Price: USD $10.31
Unit Price: USD $10.3136
≥1 USD $10.3136
≥10 USD $10.03464
≥100 USD $9.756032
≥500 USD $9.477248
≥1000 USD $9.198464
≥3000 USD $8.919698
Inventory: 224
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.710 (18.03mm)
Diameter - Barrel ID 0.570 (14.48mm)
Tab Thickness 0.140 3.56mm
Width - Outer Edges 1.060 26.92mm
Length - Overall 2.670 67.82mm
Length 67.818mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Lug, Grounding
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 4/0 AWG
Contact Finish Electro-Tin
Depth 26.92mm
HTS Code 8536.90.40.00
Color Purple
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
