LCA4/0-12-C

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminal Rectangular Connector
PDF
/
Inventory: 5395
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Color Purple
Contact Finish Electro-Tin
Wire Gauge 4/0 AWG
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole

Dimensions

Length 67.818mm
Length - Overall 2.670 67.82mm
Width - Outer Edges 1.060 26.92mm
Tab Thickness 0.140 3.56mm
Diameter - Barrel ID 0.570 (14.48mm)
Diameter - Barrel OD 0.710 (18.03mm)
Diameter - Ring ID 0.530 (13.46mm)

Compliance

RoHS Status ROHS3 Compliant
