LCA350-12-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (6.2/0)AWG 78.23mm 32.51mm Electro-Tin
PDF
/
Buying Options
Total Price: USD $14.09
Unit Price: USD $14.0888
≥1 USD $14.0888
≥10 USD $13.706
≥100 USD $13.325312
≥500 USD $12.944624
≥1000 USD $12.563848
≥3000 USD $12.183107
Inventory: 95
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.880 (22.35mm)
Diameter - Barrel ID 0.700 (17.78mm)
Tab Thickness 0.170 4.32mm
Width - Outer Edges 1.280 32.51mm
Length - Overall 3.080 78.23mm
Length 78.232mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Wire Cross Section 177.3 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 350MCM (kcmil)
Contact Finish Electro-Tin
Depth 32.51mm
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
