LCA3/0-56-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (3/0)AWG 57.65mm 24.38mm Electro-Tin
PDF
/
Buying Options
Total Price: USD $8.66
Unit Price: USD $8.6592
≥1 USD $8.6592
≥10 USD $8.42864
≥100 USD $8.194912
≥500 USD $7.960832
≥1000 USD $7.726664
≥3000 USD $7.492514
Inventory: 66
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Orange
HTS Code 8536.90.40.00
Depth 24.38mm
Contact Finish Electro-Tin
Wire Gauge 3/0 AWG
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/16 Stud
Terminal Style Single Stud Hole
Dimensions
Length 57.658mm
Length - Overall 2.270 57.66mm
Width - Outer Edges 0.960 24.38mm
Tab Thickness 0.130 3.30mm
Diameter - Barrel ID 0.510 (12.95mm)
Diameter - Barrel OD 0.640 (16.26mm)
Diameter - Ring ID 0.340 (8.64mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
