LCA2-38F-Q

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal 2AWG 36.6mm 16.8mm Tin
PDF
/
Buying Options
Total Price: USD $7.74
Unit Price: USD $7.7352
≥1 USD $7.7352
≥10 USD $7.524
≥100 USD $7.314912
≥500 USD $7.105824
≥1000 USD $6.896736
≥3000 USD $6.687789
Inventory: 111
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.420 (10.67mm)
Diameter - Barrel ID 0.310 (7.87mm)
Tab Thickness 0.100 2.54mm
Width - Outer Edges 0.660 16.76mm
Length 36.6mm

Technical

Terminal Gender FEMALE
Terminal Style Single Stud Hole
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 2 AWG
Body Plating Tin
Wire Gauge 2 AWG
Contact Finish Electro-Tin
Depth 16.8mm
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
