LCA2-12H-Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2011 Non-Insulated Terminal Rectangular Connector 2AWG 19.1mm
PDF
/
Buying Options
Total Price: USD $6.16
Unit Price: USD $6.16
≥1 USD $6.16
≥10 USD $5.99016
Inventory: 34
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.420 (10.67mm)
Diameter - Barrel ID 0.310 (7.87mm)
Tab Thickness 0.080 2.03mm
Width - Outer Edges 0.750 19.05mm
Length 48.3mm
Technical
Terminal Gender FEMALE
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 2 AWG
Body Plating Tin
Wire Gauge 2 AWG
Contact Finish Electro-Tin
Depth 19.1mm
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
