LCA2/0-38UP-X
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminal Rectangular Connector
PDF
/
Inventory: 5150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.580 (14.73mm)
Diameter - Barrel ID 0.450 (11.43mm)
Tab Thickness 0.130 3.30mm
Width - Outer Edges 0.850 21.59mm
Length - Overall 2.140 54.36mm
Length 54.356mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Wire Gauge 2/0 AWG
Color Black
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series Pan-Lug?
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
