LCA10-14F-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals LUG, NON-INSULATED 90DEG 10-12 AWG 28
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.968
≥1 USD $0.968
≥10 USD $0.946
≥100 USD $0.921536
≥500 USD $0.897424
≥1000 USD $0.873136
≥3000 USD $0.848918
Inventory: 88
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Weight 226.796213g
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Gender Female
HTS Code 8535.90.80.20
Contact Finish Electro-Tin
Wire Gauge 10 AWG
Wire Gauge (Max) 10 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 10 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/4 Stud
Terminal Style Single Stud Hole
Dimensions
Width - Outer Edges 0.420 10.67mm
Tab Thickness 0.050 1.27mm
Diameter - Barrel ID 0.130 (3.30mm)
Diameter - Barrel OD 0.220 (5.59mm)
Diameter - Ring ID 0.270 (6.86mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
