LCA1-12-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 1AWG 56.4mm 19.1mm Tin
PDF
/
Buying Options
Total Price: USD $5.89
Unit Price: USD $5.8872
≥1 USD $5.8872
≥10 USD $5.72704
≥100 USD $5.249992
≥500 USD $4.931784
Inventory: 122
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Green
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 1 AWG
Wire/Cable Gauge 1 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole
Dimensions
Length 56.642mm
Length - Overall 2.230 56.64mm
Width - Outer Edges 0.750 19.05mm
Tab Thickness 0.090 2.29mm
Diameter - Barrel ID 0.360 (9.14mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
