LAM3LB1000-121Y

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal (10.7/0)-(7.7/0)AWG 157.2mm 120.7mm Tin
PDF
/
Inventory: 5894
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Tab Thickness 0.560 14.22mm
Width - Outer Edges 5.270 133.86mm
Length - Overall 6.190 157.23mm
Length 157.226mm

Technical

Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Wire Cross Section 323 mm2
Terminal Type Lug, Grounding
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge (Min) 500 AWG
Wire Gauge (Max) 1000 AWG
Wire Gauge 500-1000MCM (kcmil)
Contact Finish Tin
Depth 120.7mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature 3 Cable Entries, With Screw
Series LAM3B
Published 2008
Packaging Bulk

Physical

Body Material Aluminium
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Aluminum

Supply Chain

Factory Lead Time 4 Weeks
